Chemical Instrumentation

The Department of Chemistry maintains a full compliment of modern chemical instrumentation. Our undergraduate students gain hands-on experience with some of these instruments in laboratory courses including the nuclear magnetic resonance spectrometer, infrared spectrometer, spectrophotometer, HPLC, PCR, etc. Senior students working on senior research projects may have the opportunity to use other instruments otherwise not introduced in teaching labs. Faculty also use the instrumentation to support their research.

Facilities

The Geology Department is located in Crawford Hall. Departmental classrooms and labs are located on the second floor at the east end of the building. The Kemp Mineral Resources Museum is located on the first floor. However, geology at Lake State goes beyond the classroom. Surrounded by a diversity of local geology spanning across the Upper Peninsula of Michigan and north of Sault Ste. Marie into Ontario, no other universities in Michigan have an opportunity quite like this right in their backyard. There is much to see and even more to learn, and what better classroom is there for geology than the field itself!

Applications include: Separation and quantification of aqueous and organic samples utilizing multiple ionization techniques

  • Agilent 6070A LC-MS/MS with Agilent Jet Stream ESI and APCI sources and 1290 Infinity II UHPLC
  • Agilent 6020B LC-TOF-MS with Agilent Jet Stream ESI and APCI sources and 1290 Infinity II UHPLC
  • Agilent 7010B GC-MS/MS with High Efficiency EI Source and 8890 GC
  • Agilent 5977B GC-MS with Inert Plus EI and CI sources, 8890 GC, and 7697A Headspace Sampler
  • Agilent 5973 GC-MS with Inert EI source and Varian/Teledyne Tekmar Velocity XPT purge and trap sampler

Applications include: Separation, purification, and quantification of aqueous and organic samples

  • Agilent 1260 Infinity II HPLC with UV/Vis detector
  • (3) Agilent 1100 series HPLC with UV/Vis detector
  • Agilent 8890 GC with FID and ECD detectors and 7697A Headspace Sampler
  • Metrohm 930 IC for anion chromatography
  • Yamazen Akros SmartFlash MPLC

Applications include: inorganic and organic molecular analysis

  • Agilent Cary 630 FTIR with diamond ATR
  • Agilent Cary 8454 UV/Vis with diode array detector, kinetics software, and temperature controlled cell
  • Molecular Devices SpectraMax M2 UV/Vis cuvette/microplate reader with fluorescence and luminescence capabilities
  • Seal Analytical AQ-1 discreet colorimetric analyzer
  • Shimadzu BioSpec-nano microvolume UV/Vis with diode array detector
  • Numerous Spec-20, Vernier Spectro-Vis Plus, and Ocean Optics educational grade spectrophotometers available for check out

Applications include: elemental composition and trace analysis

  • Agilent 7800 ICP-MS with He/H2 mode collision reaction cell and O2 plasma addition
  • Agilent 4200 MP-AES with external gas control module for N2 spectrophotometer purge and O2 plasma addition

Applications include: Structural determination of organic compounds, kinetic experiments.

  • Bruker Ascend Aeon 400 MHz NMR Spectrometer
  • Multinuclear probe with automatic tuning
  • Automatic 24 position sample changer
  • All 1-D and 2-D experiments can be fully automated

How an NMR Works

Applications include: amplification and quantification of DNA for environmental monitoring such as E. coli and Covid-19.

  • (2) Applied Biosystems Step One Plus qPCR
  • BioRad Droplet Digital PCR with Automated Droplet Generator
  • Applied Biosystems thermocycler
  • Streck Philisa rapid thermocycler
  • Biospec Nano

Applications include: Measurement of ions in and redox properties of solutions analysis

  • BASi Potentiostat with 3 electrode cell
  • Various potentiometers and ion selective electrodes, available for check out

Analytical Services

Note: Volume discounts may apply. Additional discounts available for client prepared samples. Sample containers provided at no additional cost.

Instrumentation includes:
  • Agilent 6070A LC-MS/MS with Agilent Jet Stream ESI and APCI sources and 1290 Infinity II UHPLC
  • Agilent 6020B LC-TOF-MS with Agilent Jet Stream ESI and APCI sources and 1290 Infinity II UHPLC
  • Agilent 1260 Infinity II HPLC with UV/Vis detector
  • Agilent Cary 8454 UV/Vis with diode array detector, kinetics software, and temperature controlled cell
  • Molecular Devices SpectraMax M2 UV/Vis cuvette/microplate reader with fluorescence and luminescence capabilities
  • VirTis Benchtop K Lyopholizer

Sample Sizes

Analysis Sample/ Size
Anatoxin-a Water / 0.01 L
Cylindrospermopsin Water / 0.01 L
Microcystin Water / 0.01 L
Saxitoxin Water / 0.01 L

GinaICP_000

Instrumentation includes:

  • Agilent 7800 ICP-MS with He/H2 mode collision reaction cell and O2 plasma addition
  • Agilent 4200 MP-AES with external gas control module for N2 spectrophotometer purge and O2 plasma addition
  • CEM Mars 6 microwave digestor
  • Benchtop HEPA hood systems

Method & Sample Sizes

Analysis Method Sample/Size
Metals by MP-AES SM 3111 Water / 0.1 L
Metals by ICP/MS EPA 6020 Solids / l.0 g
Sample Digestion Varies by Matrix Solids / 1.0 g (dry)
Total Mercury EPA 1631 E Water / Solid
Instrumentation includes:
  • Agilent 6070A LC-MS/MS with Agilent Jet Stream ESI and APCI sources and 1290 Infinity II UHPLC
  • Agilent 6020B LC-TOF-MS with Agilent Jet Stream ESI and APCI sources and 1290 Infinity II UHPLC
  • Agilent 7010B GC-MS/MS with High Efficiency EI Source and 8890 GC
  • Agilent 5977B GC-MS with Inert Plus EI and CI sources, 8890 GC, and 7697A Headspace Sampler
  • Agilent 5973 GC-MS with Inert EI source and Varian/Teledyne Tekmar Velocity XPT purge and trap sampler

Gas Chromatography

Method & Sample Sizes

Analysis Method Sample/Size
Organics by GC/FID EPA 8015 C Water / l.0 L
Organics by GC/MS EPA 8270 D Water / l.0 L
Organics by Purge and Trap GC/MS EPA 8260 C Water / l.0 L
Sample Extraction Varies by Matrix Water/Solids
Note: For available compounds please call.

AQ1

Instrumentation includes:
  • Metrohm 930 IC for anion chromatography
  • Agilent Cary 8454 UV/Vis with diode array detector, kinetics software, and temperature controlled cell
  • Molecular Devices SpectraMax M2 UV/Vis cuvette/microplate reader with fluorescence and luminescence capabilities
  • Shimadzu BioSpec-nano microvolume UV/Vis with diode array detector
  • Agilent 4200 MP-AES with external gas control module for N2 spectrophotometer purge and O2 plasma addition
  • Seal Analytical AQ1 – Automated Discrete Analyzer

Method & Sample Sizes

Analysis Method Sample/Size
Alkalinity SM 2320 B Water/ 0.1 L
Ammonia EPA 350.1 Water/ 0.1 L
Anions (F, Cl, Br, NO2, NO3, o-PO4, and SO4) EPA 300 Water/ 0.1 L
Biological Oxygen Demand (BOD) SM 5210 B Water/ 0.1 L
Chlorophyll (a,b, & c) SM 10200 H Water/ l.0 L
Conductivity SM 2510 B Water/ 0.1 L
Enterococci (MPN) SM 9230 D Water/ 0.1 L
Hardness SM 2340 B Water/ 0.2 L
Nitrate SM 4500 Water/ 0.1 L
Nitrate + Nitrite SM 4500 Water/ 0.1 L
ortho-Phosphate SM 4500P F Water/ 0.2 L
pH SM 4500H+ Water/ 0.1 L
Silica SM 4500-SiO2 D Water/ 0.1 L
Total coliforrn/E coli (MPN) SM 9223 Water/ 0.l L
Total Dissolved Solids SM 2540 C Water/ 0.2 L
Total Kjeldahl Nitrogen EPA 351.2 Water/ 0.l L
Total Phosphorus SM 4500P Water/ 0.2 L
Total Suspended Solids SM 2540 D Water/ 0.2 L
Turbidity EPA 180.1 Water/ 0.2 L

NewEnvironmentalAnalysisLabPCR0080-81_000

Instrumentation includes:
  • Applied Biosystems StepOne Plus qPCR
  • Applied Biosystems Thermocycler

qPCR

Sample Sizes

Analysis Method Sample/Size
Enterococcus EPA 1611 Water / 0.5 L
Human Bacteroides DRAFT EPA Method C Water / 0.5 L

Contact Us

Technical Assistance

Laboratory staff can provide technical assistance and water quality sampling equipment to volunteer monitoring programs. Please call (906) 635-2076 for more information, or email Ben Southwell at [email protected].

Location

Our facility is located in Room 342, Crawford Hall of Science at 650 W Easterday Ave, Sault Ste.Marie, MI.

Mailing Address:

Superior Analytics
Lake Superior State University
650 West Easterday Avenue
Sault Ste. Marie, MI 49783

Shipping Address:

Superior Analytics
Lake Superior State University
1100 Merdian Street
Sault Ste. Marie, MI 49783
